Cummins is a global leader in power generation technology, known for its low emissions, advanced electronics, and long-term reliability.
Key Strengths:
Global Reputation: Recognized worldwide for premium engineering quality.
Emission Compliance: Meets international environmental standards.
Advanced Control Systems: Smart controllers for remote monitoring & auto start/stop.
Mission-Critical Reliability: Used in data centers, hospitals, and telecom base stations.
Comprehensive Service: Global after-sales network and spare parts availability.
| Cummins series generator sets | |||||||||||
| Genset Model | Prime power | Standby power | Motor capacity | Engine Model | Fuel consumption | Engine | Gross Weight | Dimensions | |||
| 1H power | Cylinders | Bore * Stroke | Displacement | ||||||||
| KW | KW | KVA | ≤ g/kw.h | KW | mm | L | KG | L*W*H mm | |||
| ALD-10CF | 10 | 12.5 | 4B3.9-G11 | 214 | 22 | L4 | 102*120 | 3.9 | 765 | 1950*735*1420 | |
| ALD-16CF | 16 | 20 | 4B3.9-G11 | 214 | 22 | L4 | 102*120 | 3.9 | 765 | 1950*735*1420 | |
| ALD-20CF | / | 20 | 25 | 4B3.9-G11 | 214 | 22 | L4 | 102*120 | 3.9 | 765 | 1950*735*1420 |
| ALD-24CF | / | 24 | 30 | 4B3.9-G2 | 214 | 27 | L4 | 102*120 | 3.9 | 765 | 1950*735*1420 |
| ALD-30CF | 24 | 30 | 37.5 | 4B3.9-G12 | 214 | 30 | L4 | 102*120 | 3.9 | 765 | 1950*735*1420 |
| ALD-30CF | 30 | 37.5 | 4BT3.9-G2 | 214 | 40 | L4 | 102*120 | 3.9 | 765 | 2080*735*1420 | |
| ALD-40CF | 40 | 50 | 4BTA3.9-G2 | 216 | 55 | L4 | 102*120 | 3.9 | 830 | 2180*735*1450 | |
| ALD-50CF | 40 | 50 | 62.5 | 4BTA3.9-G2 | 216 | 55 | L4 | 102*120 | 3.9 | 830 | 2180*735*1450 |
| ALD-60CF | 50 | 60 | 75 | 4BTA3.9-G11 | 216 | 80 | L4 | 102*120 | 3.9 | 830 | 2180*735*1450 |
| ALD-75CF | 64 | 75 | 93.75 | 4BTA3.9-G11 | 216 | 80 | L4 | 102*120 | 3.9 | 850 | 2180*735*1500 |
| ALD-80CF | 75 | 80 | 100 | 4BTA3.9-G13 | 216 | 87 | L4 | 102*120 | 3.9 | 850 | 2180*735*1500 |
| ALD-80CF | 80 | 100 | 6BT5.9-G2 | 214 | 92 | L6 | 102*120 | 5.9 | 1185 | 2475*800*1470 | |
| ALD-80CF | 80 | 100 | 100 | 4BTAA3.9-G3 | 216 | 106 | L6 | 102*120 | 3.9 | 1185 | 2475*800*1470 |
| ALD-80CF | 80 | 100 | 125 | 6BT5.9-G2 | 214 | 106 | L6 | 102*120 | 5.9 | 1185 | 2475*800*1470 |
| ALD-100CF | 100 | 125 | 6BTA5.9-G2 | 211 | 116 | L6 | 102*120 | 5.9 | 1280 | 2620*800*1500 | |
| ALD-120CF | 100 | 120 | 150 | 6BTAA5.9-G2 | 208 | 130 | L6 | 102*120 | 5.9 | 1300 | 2620*800*1500 |
| ALD-150CF | 120 | 150 | 187.5 | 6BTAA5.9-G12 | 208 | 155 | L6 | 102*120 | 5.9 | 1300 | 2620*800*1500 |
| ALD-160CF | 150 | 160 | 200 | 6CTA8.3-G2 | 210 | 180 | L6 | 114*135 | 8.3 | 1600 | 2680*855*1560 |
| ALD-200CF | 180 | 200 | 250 | 6CTAA8.3-G2 | 210 | 203 | L6 | 114*135 | 8.3 | 1700 | 2900*1045*1640 |
| ALD-200CF | 200 | 250 | 6CTAA8.3-G9 | 210 | 231 | L6 | 114*135 | 8.3 | 1900 | 2900*1045*1780 | |
| ALD-250CF | 250 | 312.5 | 6LTAA9.5-G3 | 197 | 280 | L6 | 116.5*148 | 9.5 | 2000 | 2900*1045*1780 | |
| ALD-300CF | 300 | 375 | 6LTAA9.5-G1 | 210 | 320 | L6 | 116.5*148 | 9.5 | 2000 | 2900*1045*1780 | |
| ALD-350CF | 300 | 350 | 437.5 | 6ZTAA13-G3 | 204 | 380 | L6 | 130*163 | 13 | 3220 | 3400*1360*2000 |
| ALD-400CF | 350 | 400 | 500 | 6ZTAA13-G2 | 204 | 415 | L6 | 130*163 | 13 | 3220 | 3400*1360*2010 |
| ALD-400CF | / | 400 | 500 | 6ZTAA13-G4 | 193 | 415 | L6 | 130*163 | 13 | 3220 | 3400*1360*2010 |
| ALD-400CF | 400 | / | 500 | QSZ13-G2 | 193 | 440 | L6 | 130*163 | 13 | 3220 | 3400*1360*2010 |
| ALD-400CF | 400 | 450 | 500 | QSZ13-G5 | 193 | 470 | L6 | 130*163 | 13 | 3220 | 3400*1360*2010 |
| ALD-500CF | 450 | 500 | 625 | QSZ13-G10 | 196 | 509 | L6 | 130*163 | 13 | 3220 | 3420*1360*2010 |
